Metra 70-5602 Premiem System Harness for Ford 94-97 Reviews
More Picture
Metra 70-5602 Premiem System Harness for Ford 94-97 Feature
- 15 inch Long factory amplifier bypass harness
- One 8-pin power plug and one 20-pin amp plug
- Harness is plugged in at the factory amplifier and ran to the location of the aftermarket radio or amplifier
- 1-year Manufacturer's warranty
Metra 70-5602 Ford 94-97 Premiem System Harness .Product Features: 15 inch Long factory amplifier bypass harness, One 8-pin power plug and one 20-pin amp plug, Eliminates splicing when using Metra 70-5513 in Ford premium sound systems, Harness is plugged in at the factory amplifier and ran to the location of the aftermarket radio or amplifier. Connections: Yellow – 12V Constant Red – 12V Accessory Black - Ground Orange – Dash Light Dimmer/Illumination Green – Left Rear Speaker (+) Green with Black Stripe Left Rear Speaker (-) White – Left Front Speaker (+) White with Black Stripe – Left Front Speaker (-) Purple – Right Rear Speaker (+) Purple with Black Stripe – Right Rear Speaker (-) Gray – Right Front Speaker (+) Gray with Black Stripe – Right Front Speaker (-) Compatible with the following vehicles: Ford: 1992 - 1996 Bronco, 1995 - 2000 Contour, 1992 - 1997 Crown Victoria, 1992 - 1997 Econoline, 1997 - 1998 Expedition,1991 - 1997 Explorer,1992 - 1998 F-Series,1994 - 1998 Mustang, 1993 - 1997 Probe, 1990 - 1995 Taurus, 1989 - 1997 Thunderbird, 1995 - 1998 Windstar
Go tO Store Now !!
Feb 23, 2011 04:59:04
