Infinity Reference 6030cs 6.5-Inch 270-Watt Two-Way Component System Reviews
Other Picture
Infinity Reference 6030cs 6.5-Inch 270-Watt Two-Way Component System Feature
- 6-1/2-inch two-way component system with 270 Watts peak power handling and 2 Ohm impedance
- Plus One woofer cones and durable rubber surrounds for increased bass output and higher efficiency
- Edge-driven textile dome tweeters for increased power handling and reduced distortion at high output levels
- Laboratory-optimized passive crossover networks with tweeter level adjustment
- One-year warranty
Infinity's 6030cs is a 6-1/4-inch, two-way component system including Plus One woofer and 1-inch textile dome tweeter with I-mount tweeter kit and Starfish OEM adapter.
 | The Infinity Reference Series Infinity's Reference Series has been engineered to deliver best-in-class performance for those looking to replace or upgrade their factory speakers. Features like Infinity's Plus One (patent pending) woofer cones and edge-driven-dome tweeters have helped position Infinity Reference as the number-one line of automotive loudspeakers for the past six years straight. |
 Component Systems are the perfect platform when developing a system with superior imaging and staging. |
Infinity 6030cs Features
Plus One woofer cones
This patent pending technology deliver a cone with more surface area than competing models of the same size. The result is increased bass output and higher efficiency.
Rubber surrounds
This woofer surround material provides optimum cone-edge suspension and absorbs distortions that may travel up the cone edge, adding stronger low-end.
True Four Ohms
All Reference speakers feature two ohm voice coils. Original factory-installed speaker wiring in many cars is 18-22 gauge. This wire, and heating in the voice coil when power is applied, increase the impedance "seen" by the amplifier or head unit. The impedance of Reference Speakers has been adjusted to compensate for this increase and can be safely driven by any head unit.
Edge-driven textile dome tweeter
These are not commonly used w-domes, but fully-edge-driven domes like those found in better home audio speakers. The benefit is increased power handling and reduced distortion at high output levels. This technology also allows for better integration with the mid/woofer.
Crossover network with tweeter adjustment
Each Infinity Reference component system includes a pair of laboratory optimized passive crossover networks that include tweeter adjustment. If the tweeters are located low in the doors or if you are looking for a brighter sound, you can set the tweeter at +3dB.
Versatile Mounting
To facilitate proper installation and location of the tweeter, each Reference component system includes Infinity's patented I-Mount (patent no. 5,859,917) tweeter mounting kit including the Starfish OEM adapter.
Infinity 6030cs Specifications
| Power Handling, RMS: | 75 Watts |
| Power Handling, Peak: | 225 Watts |
| Sensitivity (2.83V @ 1m): | 92dB |
| Frequency Response: | 67Hz - 21kHz |
| Impedance: | 2 Ohms |
| Mounting Depth: | 2-1/4 inches |
About Infinity
Infinity was founded in 1968 on a unique blend of technology, performance, and design. Today, Infinity offers three tiers of automotive speakers comparable to the best home-audio components. Infinity Kappa Perfect, Kappa, and Reference Series speakers deliver performance that rivals the best the competition has to offer.
What's in the Box
Two Woofers, Two Tweeters, Two Crossovers, Two Grilles, Mounting Hardware, User Manual
Infinity Reference Series Component Systems
Component Systems are the perfect platform when developing a system with superior imaging and staging. These systems consist of a separate tweeter, crossover, and midrange/woofer. Infinity offers three levels of component systems. Each offers "best in class" performance and delivers incredible sonic detail and realism.
 |  |  |
| Infinity Reference 5030cs 5.25-Inch 225-Watt Two-Way Component System | Infinity Reference 6030cs 6.25-Inch 270-Watt Two-Way Component System | Infinity Reference 6830cs 6 x 8/5 x 7-Inch 270-Watt Two-Way Component System |
Looking for a more moving audio experience? Take Infinity car audio for a ride. Innovative materials and breakthrough engineering have always put Infinity products out in front of the competition’s. So expect extreme output from these speakers, but be prepared for accuracy and detail that may surprise you. Infinity Reference Series loudspeakers continue to be the top-selling premium speakers in the world. For instance, the 6-1/2-inch Reference coaxial model has been the number-one-selling car audio multielement speaker for five years straight. With proprietary features such as patent-pending Plus One cones, true 4-ohm topology, UniPivot edge-driven tweeters and the industry-leading Intermount III and I-Mount mounting systems, as well as the Starfish tweeter-mounting adapter, Reference Series speakers leave the competition scrambling to keep up.
